DATAEAGLE 373x Master transmitter configuration, 15383
Configuration option for the Master role for a unit in the PROFIBUS DP network control section with DATAEAGLE 373x. The base module and communication option must be ordered separately. More
Code: 15383
Configuration option for the Master role for a unit in the PROFIBUS DP network control section with DATAEAGLE 373x. The base module and communication option must be ordered separately. More
Code: 15383
Master Configuration for DATAEAGLE 373x
Item 15383 defines the role of the DATAEAGLE 373x radio unit in a PROFIBUS wireless connection. The master is connected on the control side of the network. This is a configuration option for the base module, not a standalone transmitter or receiver.
Are you enquiring about this option, or the whole set?
Please send us a network diagram, the number of units and your transmission requirements. We will coordinate the modules, communication and configuration.
Using the configuration
Select the ‘Master’ role for the radio unit on the control system side. The remote unit must have the corresponding ‘Slave’ role.
The terms ‘Master’ and ‘Slave’ here refer to the roles of the DATAEAGLE radio units. They do not refer to the number or designation of end devices in an industrial network.
Configuration details
| Manufacturer | SCHILDKNECHT |
|---|---|
| Configuration item code | 15383 |
| Item type | Configuration without radio hardware |
| Intended for | DATAEAGLE 373x Compact and X-treme |
| The role of the station | Master - the network control unit side |
| Supported protocols and limits | Determines the selected communication option |
| Modules and accessories in this item | They are not included |
Communication options and limits
The number of radio receivers and remote stations is determined by the communication option, not by the Master or Slave role itself. 15380 Point-to-Point allows for one receiver and four PROFIBUS DP stations, 15381 Multipoint up to four receivers and a total of four PROFIBUS DP stations. These two communication options do not support PROFIsafe.
Contents of the offer and required components
The configuration item itself does not include radio units. Select the core modules 373x Compact 15375 or 373x X-treme 15376, the communication option for individual units and the Master and Slave roles. We will specify the number, design and communication functions separately in the quotation.
We will supply the antennas, any necessary antenna cables, mounting accessories and industrial network connections. We will confirm the price, availability and scope of configuration before you place your order.
Documentation to download
DATAEAGLE TV videos, tutorials and webinars
Selected videos from the manufacturer in English. Start with a brief introduction, or go for in-depth webinars and tutorials.
Wireless PROFIBUS - DATAEAGLE 3000
An introduction to the PROFIBUS DP wireless connectivity range and examples of its use.
Open the video on YouTubeHow does DATAEAGLE radio transmission work?
The difference between a cable connection and a radio link, and an explanation of data pre-processing in the DATAEAGLE system.
Open the video on YouTubeThe videos demonstrate the principles behind the DATAEAGLE 3000 series and show examples of its use. Specific functions and connections depend on the model selected and its configuration. The hardware manuals relate to the corresponding radio units, not to the communication or configuration item itself.
Industrial Wireless Webinars - 3 videos in English

1. Design of an industrial wireless link
The basics of power transmission, differences compared to cables and slip rings, project planning and practical demonstrations.
Watch the English webinar
2. WLAN, Bluetooth and their uses
A comparison of radio technologies, signal propagation, network convergence and examples from the field of automation.
Watch the English webinar
3. Applications, diagnostics and antennas
Industry examples, a demonstration of PROFINET/PROFIsafe diagnostics in the DATAEAGLE Wizard, and the selection and positioning of antennas.
Watch the English webinarFirmware update guides - in English
Main firmware update
An older demonstration of how to connect the unit to a PC and update the main CPU’s firmware. The instructions in the video are in English.
Communication interface firmware update
An older English guide to updating the interface for the DATAEAGLE 3000 and 4000 series.
Older examples from2016. The programme interface and procedure vary depending on the model. Before updating, please check the exact model, hardware and firmware versions, and ensure you have the correct update file. FOXON’s technical support team will help you with the correct procedure.
More videos on the DATAEAGLE TV channel - The channel also features German videos; the selection in this section is in English.
Frequently Asked Questions
Does this price include a complete wireless connection?
This card is a configuration item. The complete connection package also includes the corresponding base modules, communication options and accessories.
Does the configuration also specify the supported protocol?
The communication option determines the supported protocols and device limits. The configuration defines the roles and arrangement of the radio units.
Can the Compact and X-treme be combined?
We will select the appropriate version for each installation site. We will verify the suitability of the combination, the radio option and the compatibility of the configurations when designing the system.
What else should be added to the proposal?
Please send us the wiring diagram, the number of radio sites, the number of end devices, the protocol, the communication times, the distance and photographs of the site.
Why buy DATAEAGLE from FOXON
Schildknecht Distributor
We are the distributor of Schildknecht products for the Czech Republic and Slovakia. We have been representing the manufacturer since 2015.
Products in stock
We hold Schildknecht products in stock. We will confirm the availability of the selected model and the required quantity before you place your order.
From single items to larger batches
We can arrange deliveries ranging from single items to larger batches. We can also help organise deliveries for the repeat production of machinery and equipment.
Technical support and consultancy
We can help you choose modules, communication options, configurations and antennas. We provide technical support and advice on installation and operation.
DATAEAGLE enquiry - 15383
Please quote code 15383, the required quantity and whether you are enquiring about a single item or a complete assembly. For the proposal, please attach a network diagram, a protocol, the number of radio sites and end devices, the distance, photographs of the site and the required response times.
