DATAEAGLE 373 × Slave receiver configuration, 15384

DATAEAGLE 373 × Slave receiver configuration, 15384

FOXON PLUS

Schildknecht

Configuration option for the ‘Slave’ role for a unit on the remote section of a PROFIBUS DP network with a DATAEAGLE 373x. The base module and communication option must be ordered separately. More

Code: 15384

0 EUR excl. VAT (0 EUR Incl. VAT)
Delivery in 2-3 weeks
pcs
(0 pcs In stock)

Rezervace termínu

Get a quote
Schildknecht

Configuration option for the ‘Slave’ role for a unit on the remote section of a PROFIBUS DP network with a DATAEAGLE 373x. The base module and communication option must be ordered separately. More

Code: 15384

SCHILDKNECHT DATAEAGLE 3000

Slave Configuration for DATAEAGLE 373x

Item 15384 defines the role of the DATAEAGLE 373x radio unit in a PROFIBUS wireless connection. The slave is connected on the PROFIBUS DP remote station side. This is a configuration option for the base module, not a standalone transmitter or receiver.

Are you enquiring about this option, or the whole set?
Please send us a network diagram, the number of units and your transmission requirements. We will coordinate the modules, communication and configuration.

Enquire about the configuration and complete set-up
SlaveThe role of the radio unit
DATAEAGLE 373xDesignated series
ConfigurationStandalone option without hardware

Using the configuration

Select the ‘Slave’ role for the radio unit on the remote PROFIBUS DP segment. A ‘Master’ unit is required at the other end of the link.

The terms ‘Master’ and ‘Slave’ here refer to the roles of the DATAEAGLE radio units. They do not refer to the number or designation of end devices in an industrial network.

Configuration details

ManufacturerSCHILDKNECHT
Configuration item code15384
Item typeConfiguration without radio hardware
Intended forDATAEAGLE 373x Compact and X-treme
The role of the stationSlave - Remote Stations page
Supported protocols and limitsDetermines the selected communication option
Modules and accessories in this itemThey are not included

Communication options and limits

The number of radio receivers and remote stations is determined by the communication option, not by the Master or Slave role itself. 15380 Point-to-Point allows for one receiver and four PROFIBUS DP stations, 15381 Multipoint up to four receivers and a total of four PROFIBUS DP stations. These two communication options do not support PROFIsafe.

Contents of the offer and required components

The configuration item itself does not include radio units. Select the core modules 373x Compact 15375 or 373x X-treme 15376, the communication option for individual units and the Master and Slave roles. We will specify the number, design and communication functions separately in the quotation.

We will supply the antennas, any necessary antenna cables, mounting accessories and industrial network connections. We will confirm the price, availability and scope of configuration before you place your order.

Documentation to download

DATAEAGLE TV videos, tutorials and webinars

Selected videos from the manufacturer in English. Start with a brief introduction, or go for in-depth webinars and tutorials.

EN · 1:29

Wireless PROFIBUS - DATAEAGLE 3000

An introduction to the PROFIBUS DP wireless connectivity range and examples of its use.

Open the video on YouTube
EN · 3:40

How does DATAEAGLE radio transmission work?

The difference between a cable connection and a radio link, and an explanation of data pre-processing in the DATAEAGLE system.

Open the video on YouTube

The videos demonstrate the principles behind the DATAEAGLE 3000 series and show examples of its use. Specific functions and connections depend on the model selected and its configuration. The hardware manuals relate to the corresponding radio units, not to the communication or configuration item itself.

Industrial Wireless Webinars - 3 videos in English
Industrial Wireless Webinar - Part 1: Designing an Industrial Wireless Link, in English
EN · 38:26 · 2020
1. Design of an industrial wireless link

The basics of power transmission, differences compared to cables and slip rings, project planning and practical demonstrations.

Watch the English webinar
Industrial Wireless Webinar - Part 2: WLAN, Bluetooth and their applications, in English
EN · 46:39 · 2020
2. WLAN, Bluetooth and their uses

A comparison of radio technologies, signal propagation, network convergence and examples from the field of automation.

Watch the English webinar
Industrial Wireless Webinar - Part 3: Applications, Diagnostics and Antennas, in English
EN · 44:47 · 2020
3. Applications, diagnostics and antennas

Industry examples, a demonstration of PROFINET/PROFIsafe diagnostics in the DATAEAGLE Wizard, and the selection and positioning of antennas.

Watch the English webinar
Firmware update guides - in English
EN · 2:40 · 2016
Main firmware update

An older demonstration of how to connect the unit to a PC and update the main CPU’s firmware. The instructions in the video are in English.

Older examples from2016. The programme interface and procedure vary depending on the model. Before updating, please check the exact model, hardware and firmware versions, and ensure you have the correct update file. FOXON’s technical support team will help you with the correct procedure.

More videos on the DATAEAGLE TV channel - The channel also features German videos; the selection in this section is in English.

Frequently Asked Questions

Does this price include a complete wireless connection?

This card is a configuration item. The complete connection package also includes the corresponding base modules, communication options and accessories.

Does the configuration also specify the supported protocol?

The communication option determines the supported protocols and device limits. The configuration defines the roles and arrangement of the radio units.

Can the Compact and X-treme be combined?

We will select the appropriate version for each installation site. We will verify the suitability of the combination, the radio option and the compatibility of the configurations when designing the system.

What else should be added to the proposal?

Please send us the wiring diagram, the number of radio sites, the number of end devices, the protocol, the communication times, the distance and photographs of the site.
